| RB25DET BX8265 TURBOCHARGER KIT |
 |
|
|
|
Click image to enlarge.
Click part Ref.No. for details. |
 |
| TURBOCHARGER REPAIR PARTS |
|
| 1 |
Part |
CHRA |
| Quantity |
1 |
| Part No. |
TB403B-CRA07 |
| MSRP(1pc) |
$1,390.00 |
|
|
| 1 |
Part |
COMPRESSOR HOUSING |
| Quantity |
1 |
| Part No. |
TB401B-COH10 |
| MSRP(1pc) |
$250.00 |
|
|
| |
| 1 |
Part |
ACTUATOR |
| Quantity |
1 |
| Part No. |
TB401B-ACT07 |
| MSRP(1pc) |
$180.00 |
|
|
|
| 1 |
Part |
TURBINE HOUSING |
| Quantity |
1 |
| Part No. |
TB401B-TBH11 |
| MSRP(1pc) |
$470.00 |
|
|
|
|
|
|
| |
| OIL FEED |
|
| 2 |
Part |
MESH HOSE 160mm |
| Quantity |
1 |
| Part No. |
TB401B-OFP15 |
| MSRP(1pc) |
$11.00 |
|
|
| 3 |
Part |
BANJO BOLT M12 |
| Quantity |
1 |
| Part No. |
TB401B-BJB07 |
| MSRP(1pc) |
$7.00 |
|
|
|
| 4 |
Part |
WASHER M12 |
| Quantity |
3 |
| Part No. |
TB401B-WAS04 |
| MSRP(1pc) |
$1.00 |
|
|
| 5 |
Part |
BANJO FITTING M12 4AN |
| Quantity |
1 |
| Part No. |
TB401B-FIT10 |
| MSRP(1pc) |
$7.00 |
|
|
|
| 6 |
Part |
FITTING 4AN M to F 90° |
| Quantity |
1 |
| Part No. |
TB401B-FIT01 |
| MSRP(1pc) |
$7.00 |
|
|
| 7 |
Part |
FITTING M12☓P1.25 4AN |
| Quantity |
1 |
| Part No. |
TB401B-FIT07 |
| MSRP(1pc) |
$6.00 |
|
|
|
|
|
|
| |
| OIL RETURN |
|
| 8 |
Part |
OIL RETURN GASKET |
| Quantity |
1 |
| Part No. |
TB401B-ORG01 |
| MSRP(1pc) |
$2.00 |
|
|
| 9 |
Part |
OIL DRAIN PIPE |
| Quantity |
1 |
| Part No. |
TB401B-ODP07 |
| MSRP(1pc) |
$32.00 |
|
|
|
| 10 |
Part |
BOLT M6 P1.0 16mm |
| Quantity |
2 |
| Part No. |
TB401B-WBT01 |
| MSRP(1pc) |
$1.00 |
|
|
|
|
|
|
|
|
| |
| WATER FEED |
|
| 11 |
Part |
WATER BOLT M14 P1.5 |
| Quantity |
1 |
| Part No. |
TB401B-WTB01 |
| MSRP(1pc) |
$4.00 |
|
|
| 12 |
Part |
WASHER M14 |
| Quantity |
3 |
| Part No. |
TB401B-WAS02 |
| MSRP(1pc) |
$1.00 |
|
|
|
| 13 |
Part |
BANJO FITTING M14 4AN |
| Quantity |
1 |
| Part No. |
TB401B-FIT21 |
| MSRP(1pc) |
$7.00 |
|
|
| 14 |
Part |
MESH HOSE 380mm |
| Quantity |
1 |
| Part No. |
TB401B-OFP07 |
| MSRP(1pc) |
$13.00 |
|
|
|
| 15 |
Part |
FITTING 4AN M to F 90° |
| Quantity |
1 |
| Part No. |
TB401B-FIT01 |
| MSRP(1pc) |
$7.00 |
|
|
| 16 |
Part |
FITTING M14 P1.5 4AN |
| Quantity |
1 |
| Part No. |
TB401B-FIT08 |
| MSRP(1pc) |
$6.00 |
|
|
|
|
|
|
| |
| WATER RETURN |
|
| 17 |
Part |
FITTING M14 P1.5 4AN |
| Quantity |
1 |
| Part No. |
TB401B-FIT08 |
| MSRP(1pc) |
$6.00 |
|
|
| 18 |
Part |
WASHER M14 |
| Quantity |
1 |
| Part No. |
TB401B-WAS02 |
| MSRP(1pc) |
$1.00 |
|
|
|
| 19 |
Part |
FITTING 4AN M to F 90° |
| Quantity |
1 |
| Part No. |
TB401B-FIT01 |
| MSRP(1pc) |
$7.00 |
|
|
| 20 |
Part |
MESH HOSE 470mm |
| Quantity |
1 |
| Part No. |
TB401B-OFP08 |
| MSRP(1pc) |
$13.00 |
|
|
|
| 21 |
Part |
FITTING 11mm 4AN |
| Quantity |
1 |
| Part No. |
TB401B-FIT22 |
| MSRP(1pc) |
$5.00 |
|
|
| 22 |
Part |
HOSE BAND 7-16mm |
| Quantity |
1 |
| Part No. |
TB401B-HBD06 |
| MSRP(1pc) |
$1.00 |
|
|
|
|
|
|
| |
| OTHER HARDWARE |
|
| 23 |
Part |
COMPRESSOR OUT GASKET |
| Quantity |
1 |
| Part No. |
TB401B-COG05 |
| MSRP(1pc) |
$9.00 |
|
|
| 24 |
Part |
TURBINE IN
GASKET |
| Quantity |
1 |
| Part No. |
TB401B-TIG05 |
| MSRP(1pc) |
$18.00 |
|
|
|
| 25 |
Part |
TURBINE OUT GASKET |
| Quantity |
1 |
| Part No. |
TB401B-TOG07 |
| MSRP(1pc) |
$18.00 |
|
|
| 26 |
Part |
LOCK PLATE |
| Quantity |
2 |
| Part No. |
TB401B-LKP02 |
| MSRP(1pc) |
$6.00 |
|
|
|
| 27 |
Part |
STUD BOLT M8 P1.25 35mm
/ 18-10.5mm |
| Quantity |
2 |
| Part No. |
TB401B-STB04 |
| MSRP(1pc) |
$3.00 |
|
|
| 28 |
Part |
VACUUM HOSE
5☓11mm |
| Quantity |
1 |
| Part No. |
TB401B-SLH03 |
| MSRP(1pc) |
$5.00 |
|
|
|
| 29 |
Part |
HEAT RESISTANT HOSING |
| Quantity |
1 |
| Part No. |
TB401B-TIT01 |
| MSRP(1pc) |
$25.00 |
|
|
|
|
|
|
|
|
| |
| MISC. |
|
| 30 |
Part |
BOLT SMOOTH
PASTE |
| Quantity |
1 |
| Part No. |
PB6150-BSP01 |
| MSRP(1pc) |
$2.00 |
|
|
| 31 |
Part |
ACTUATOR SPRING
BLACK |
| Quantity |
1 |
| Part No. |
TB401B-SPR07 |
| MSRP(1pc) |
$7.00 |
|
|
|
|
| 32 |
Part |
ACTUATOR SPRING RED |
| Quantity |
1 |
| Part No. |
TB401B-SPR10 |
| MSRP(1pc) |
$9.00 |
|
|
| 33 |
Part |
ACTUATOR SPRING PINK |
| Quantity |
1 |
| Part No. |
TB401B-SPR11 |
| MSRP(1pc) |
$9.00 |
|
|
|
| 34 |
Part |
ACTUATOR SPRING
BLUE |
| Quantity |
1 |
| Part No. |
TB401B-SPR12 |
| MSRP(1pc) |
$7.00 |
|
|
| 35 |
Part |
STRAIGHT ACTUATOR NIPPLE |
| Quantity |
1 |
| Part No. |
TB401B-SAN01 |
| MSRP(1pc) |
$6.00 |
|
|
|
|
|
|
| |
| |
 |
