TURBINE OUTLET PIPE for 1JZ-GTE |
| |
| Large Capacity For High Flow, Maximise Your 1JZ Potential! |
| |
 |
|
| The internal shape is made smooth to optimize the large volumetric gas flow. With a well designed flange for ease of installation. This products design will maximize the Tomei ARMS Turbos performance potential. It was designed with the exit diameter of Φ76.3mm, yet with the same flange bolt pattern of the stock front pipe. |
|
|
| |
| APPLICATION |
PART NUMBER |
JZX100 / JZX110 / JZX110W / JZZ30 LATE MODEL /
JZS171 / JZS171W |
TB6020-TY04A |
|
|
| |
| MSRP $390.00 (USD) |
| |
 |
|
 |
| TURBO : TOMEI ARMS M8280 |
|
TURBO : STD |
|
| |
| |
MATERIAL |
EXIT
DIA.(Φ) |
VOLUME
(cc) |
FLANGE
THICKNESS
(mm) |
WEIGHT(kg) |
| TOMEI |
SUS304 |
76.3 |
810 |
12 |
1.8 |
| STD |
STEEL |
60 |
620 |
13.8 |
2.5 |
|
|
| |
 |
| |
 |
|
| |
| Allows the exhaust gases to smoothly exit from the turbo without interference. The Lost Wax method was used for optimum strength and enhanced looks. |
|
|
| |
 |
| ■３ INCH (φ76.3mm) COMPATIBLE |
|
|
| |
120% increase over stock.
Greatly reduces the secondary exhaust gas pressure. |
|
|
| |
|
| |
|
|
| |
