STOCK COMPARISION
The exhaust flow design was the main focus in the pipe design, the best pipe thickness for weight and strength with pipe diameter to suit torque and all power gains throughout the entire power band.
TOMEI
STD
MATERIAL
TITANIUM

STAINLESS

MAIN PIPE DIAMETER
80
60.5
MAIN PIPE THICKNESS
1mm
1.2mm
SILENCER DIAMETER
152
N/A
SILENCER BROAD THICKNESS
1mm
N/A
TIP DIAMETER
115
N/A
TIP BROAD THICKNESS
1mm
N/A
FLANGE THICKNESS
6mm

9mm

LAYOUT
SINGLE SIDED
LEFT&RIGHT SPLIT
WEIGHT
4.7kg
19.6kg
14.9 kg LIGHTER!
STANDARD


 RACING LAYOUT

For the best exhaust efficiency results minimal bends and curves was the design focus points on this product which aided with the supreme results.

 3 PEICE ASSEMBLY
No flanges were fitted for increased weight savings and for a better finish with the race look secure springs and clamp methods.

 DRY RACE SOUND

The instinctive sound of a true race exhaust sound that a Titanium material exhaust gives will intoxicate you with the dry race exhaust sound.

 PERFORMANCE VALUE
The best performance is made possible with the best materials and still with keeping it within everyonefs reach.


 KIT CONTENTS
MAIN PIPE A
MAIN PIPE B
SILENCER ASSEMBLY
SILENCER BAND
SILENCER BAND RUBBER
GASKETS
WASHERS M12x 2
NUT M12x 2
CLAMP BAND x2
SPRINGS x4
MUFFLER HANGER
SOUND REDUCER ver.2
FLANGE BOLT M8
FLANGE NUT M8
BOLT SMOOTH PASTE
PART NUMBERF
TB6090-HY01A (Previous P/N 440002)
MSRP $1,090.00 (USD)
* DESIGNED FOR TRUE COMPETITION OFF ROAD USE ONLY.
* NOT COMPATIBLE WITH 380GT MODELS.

Additional bolt holes may be required when using the sound reducer ver.2 .
Click here for details.



This will cover the gap on the other side that is no longer used.

PART NUMBERF663006
MSRP $90.00 (USD)


@

@
