| PART No. |
PRODUCT NAME |
MSRP(USD) |
|
| TB6090-MZ02A |
FULL TITANIUM MUFFLER KIT
EXPREME Ti NB MIATA
INVENTORY¨
|
$990.00 |
 |
|
| |
 |
 |
 |
|
 |
|
 |
|
 |
|
 |
|
 |
|
 |
| |
Application:
MAZDA NB MIATA
|
| |
 |
 |
| |
| FULL TITANIUM MUFFLER SPECIFICATION |
| |
TOMEI |
OEM |
| PART No. |
TB6090-MZ02A |
- |
| MATERIAL |
TITANIUM |
- |
| MAIN PIPE DIAMETER |
2.38inch(60.5mm) |
1.96inch(50.0mm) |
| MAIN PIPE THICKNESS |
1.0mm |
- |
| SUB SILENCER DIAMETER |
4.64inch(118.0mm) |
- |
| SUB SILENCER THICKNESS |
1.0mm |
- |
| SILENCER DIAMETER |
4.64inch
(118.0mm) |
11.0x19.6x6.69inch
(280x500x170mm) |
| SILENCER THICKNESS |
1.0mm |
- |
| EXIT DIAMETER |
3.50inch(89.1mm) |
2.36inch(60.0mm) |
| EXIT THICKNESS |
1.0mm |
- |
| FLANGE THICKNESS |
8.0mm |
8.0mm |
| WEIGHT |
19.2lbs (8.7kg) |
21.8lbs (9.9kg) |
|
| |
| |
 |
| Only Muffler installed |
 |
| |
| |
 |
| This kit includes all the components necessary for installation including the bolts and nuts. Bolt Smooth Paste is also included to help prevent the bolts becoming seized under heat. |
|
|
 |
| |
|
