TARGET HP (HP)
400
BEARING TYPE
BALL BEARING
INITIAL BOOST SETTING (kgf/cm2)
1.0
COMPRESSOR WHEEL
ⒶIND(mm)
52.6
ⒷEXD(mm)
68.0
TRIM
60
BLADES
6/6
MATERIAL
A2618
PRODUCTION
CNC BILLET
TURBINE WHEEL
ⒸEXD(mm)
54.0
ⒹIND(mm)
61.0
TRIM
79
BLADES
9
MATERIAL
K418
PRODUCTION
CAST
COMPRESSOR HOUSING
IND(mm)
53.6
EXD(mm)
41.63
A/R
0.78
TURBINE HOUSING
IND(mm)
45.0
EXD(mm)
EJ
A/R
0.57
