TARGET HP (HP)
650
BEARING TYPE
BALL BEARING
INITIAL BOOST SETTING (kgf/cm2)
1.0
COMPRESSOR WHEEL
ⒶIND(mm)
52.6
ⒷEXD(mm)
68.0
TRIM
60
BLADES
6/6
MATERIAL
A2618
PRODUCTION
CNC BILLET
TURBINE WHEEL
ⒸEXD(mm)
58.8
ⒹIND(mm)
67.0
TRIM
77
BLADES
9
MATERIAL
K418
PRODUCTION
CAST
COMPRESSOR HOUSING
IND(mm)
53.5
EXD(mm)
38.75
A/R
0.74
TURBINE HOUSING
IND(mm)
T25
EXD(mm)
RB26DETT
A/R
0.73
