TARGET HP (HP)
450
BEARING TYPE
BALL BEARING
INITIAL BOOST SETTING (kgf/cm2)
1.0
COMPRESSOR WHEEL
ⒶIND(mm)
54.8
ⒷEXD(mm)
76.2
TRIM
52
BLADES
6/6
MATERIAL
A2618
PRODUCTION
CNC BILLET
TURBINE WHEEL
ⒸEXD(mm)
58.8
ⒹIND(mm)
67.0
TRIM
77
BLADES
9
MATERIAL
K418
PRODUCTION
CAST
COMPRESSOR HOUSING
IND(mm)
55.8
EXD(mm)
42.62
A/R
0.57
TURBINE HOUSING
IND(mm)
T3
EXD(mm)
RB25
A/R
0.57
